System Architecture

../_images/system_architecture.png
align:center

Containers

medco-unlynx

The software executing the distributed cryptographic protocols, based on Unlynx.

i2b2-medco

The i2b2 stack (all the cells), with the addition of the MedCo i2b2 cell to process the queries. This cell communicates with medco-unlynx to execute the distributed cryptographic protools.

irct

glowing-bear

nginx web server serving GLowing Bear and the crypto module

keycloak

WildFly only in 1 of the nodes oidc identity provider

postgresql

The SQL database used by all other services, contains all the data.

pg-admin

A web-based administration tool for the PostgreSQL database.

nginx

web server and reverse proxy

php-fpm

PHP processor running with FPM (FastCGI Process Manager), used by Nginx. Executes the PHP code needed to serve the genomic annotations.
